HNBR O-Rings - 70 Shore A

HNBR O-Rings - 70 Shore A
Filter results
close
ID (Inner diameter)
mm
mm
CS (Cross Section)
mm
mm
AS568 Size Chart
AS568 Size Chart
close
keyboard_arrow_down
Color
Color
close
keyboard_arrow_down
In stock
In stock
close
keyboard_arrow_down
Product Hardness Material Color Stock From price
O-ring 253.57x6.99 - HNBR- 90 Shore A - Black - ORS175694
O-ring 253.57 mm x 6.99 mm 90 Shore A HNBR Black 78   € 29,94 Details
O-ring 85x2 - HNBR - AED - 70 Shore A - Black - ORS97881
O-ring 85 mm x 2 mm 70 Shore A HNBR Black 14   € 24,60 Details
O-ring 55x2 - HNBR - AED - 70 Shore A - Black - ORS97882
O-ring 55 mm x 2 mm 70 Shore A HNBR Black 2478   € 1,98 Details
O-ring 300x8 - HNBR - AED - 70 Shore A - Black - ORS97883
O-ring 300 mm x 8 mm 70 Shore A HNBR Black 20   € 53,61 Details
O-ring 144x4 - HNBR - AED - 70 Shore A - Black - ORS97884
O-ring 144 mm x 4 mm 70 Shore A HNBR Black 57   € 53,89 Details
O-ring 100x3 - HNBR - AED - 70 Shore A - Black - ORS97885
O-ring 100 mm x 3 mm 70 Shore A HNBR Black 0   € 6,13 Details Quote
O-ring 55x4 - HNBR - AED - 70 Shore A - Black - ORS97886
O-ring 55 mm x 4 mm 70 Shore A HNBR Black 1112   € 4,54 Details
O-ring 95x2.5 - HNBR - AED - 70 Shore A - Black - ORS97887
O-ring 95 mm x 2.5 mm 70 Shore A HNBR Black 91   € 20,69 Details
O-ring 30x4 - HNBR - AED - 70 Shore A - Black - ORS97888
O-ring 30 mm x 4 mm 70 Shore A HNBR Black 1822   € 2,27 Details
O-ring 38x2 - HNBR - AED - 70 Shore A - Black - ORS97889
O-ring 38 mm x 2 mm 70 Shore A HNBR Black 4936   € 1,22 Details
O-ring 104x3 - HNBR - AED - 70 Shore A - Black - ORS97890
O-ring 104 mm x 3 mm 70 Shore A HNBR Black 742   € 5,70 Details
O-ring 5x2.5 - HNBR - AED - 70 Shore A - Black - ORS109448
O-ring 5 mm x 2.5 mm 70 Shore A HNBR Black 820   € 0,28 Details
O-ring 8x1 - HNBR - AED - 70 Shore A - Black - ORS109450
O-ring 8 mm x 1 mm 70 Shore A HNBR Black 0   € 0,22 Details Quote
O-ring 8.73x1.78 - HNBR - AED - 70 Shore A - Black - ORS109452
O-ring 8.73 mm x 1.78 mm 70 Shore A HNBR Black 14370   € 0,20 Details
O-ring 9.1x1.6 - HNBR - AED - 70 Shore A - Black - ORS109460
O-ring 9.1 mm x 1.6 mm 70 Shore A HNBR Black 238   € 0,18 Details
O-ring 10x2 - HNBR - AED - 70 Shore A - Black - ORS109466
O-ring 10 mm x 2 mm 70 Shore A HNBR Black 15192   € 0,27 Details
O-ring 11.8x2.4 - HNBR - AED - 70 Shore A - Black - ORS109470
O-ring 11.8 mm x 2.4 mm 70 Shore A HNBR Black 10541   € 0,50 Details
O-ring 11.91x2.62 - HNBR - AED - 70 Shore A - Black - ORS109473
O-ring 11.91 mm x 2.62 mm 70 Shore A HNBR Black 5740   € 0,41 Details
O-ring 15x1.78 - HNBR - AED - 70 Shore A - Black - ORS109482
O-ring 15 mm x 1.78 mm 70 Shore A HNBR Black 161   € 0,26 Details
O-ring 15.08x2.62 - HNBR - 70 Shore A - Black - ORS109485
O-ring 15.08 mm x 2.62 mm 70 Shore A HNBR Black 0   € 0,53 Details Quote
O-ring 17.8x2.4 - HNBR - 70 Shore A - Black - ORS109494
O-ring 17.8 mm x 2.4 mm 70 Shore A HNBR Black 297   € 0,68 Details
O-ring 19x3 - HNBR - 70 Shore A - Black - ORS109497
O-ring 19 mm x 3 mm 70 Shore A HNBR Black 171   € 0,85 Details
O-ring 23x1.5 - HNBR - 70 Shore A - Black - ORS109510
O-ring 23 mm x 1.5 mm 70 Shore A HNBR Black 0   € 0,44 Details Quote
O-ring 25.8x3.53 - HNBR - 70 Shore A - Black - ORS109522
O-ring 25.8 mm x 3.53 mm 70 Shore A HNBR Black 2555   € 1,37 Details
O-ring 26.3x2.4 - HNBR - 70 Shore A - Black - ORS109526
O-ring 26.3 mm x 2.4 mm 70 Shore A HNBR Black 5520   € 0,91 Details
O-ring 29x3 - HNBR - 70 Shore A - Black - ORS109538
O-ring 29 mm x 3 mm 70 Shore A HNBR Black 4818   € 1,38 Details
O-ring 32x2 - HNBR - 70 Shore A - Black - ORS109551
O-ring 32 mm x 2 mm 70 Shore A HNBR Black 0   € 0,80 Details Quote
O-ring 34x3 - HNBR - 70 Shore A - Black - ORS109556
O-ring 34 mm x 3 mm 70 Shore A HNBR Black 5369   € 1,56 Details
O-ring 41x2 - HNBR - 70 Shore A - Black - ORS109579
O-ring 41 mm x 2 mm 70 Shore A HNBR Black 0   € 1,01 Details Quote
O-ring 42.5x3.55 - HNBR - 70 Shore A - Black - ORS109582
O-ring 42.5 mm x 3.55 mm 70 Shore A HNBR Black 27   € 2,47 Details

Need an O-ring that has to be resistant to chemicals, abrasion and heat? Then the HNBR O-Ring 70 Shore A is the one you need. Contrary to the NBR the HNBR is way more durable and robust. This makes the HNBR perfect when used in harsh environments. Examples include the automotive and gas & oil industries. Besides the fact that it is a good O-ring in harsh environments it is also a great choice when used in extreme temperatures. The Temperature range of the O-ring HNBR is -30°C to +150°C (-22 °F to 302 °F). Because of the high saturation level it has the perfect balance of flexibility and strength of 70 shore. With this O-ring, you can be confident that even when under pressure they will perform excellently. As the cherry on top, the HNBR O-Ring is also resistant to losing certain properties when exposed to various chemicals, oils and other liquids for long periods of time. The HNBR 70 Shore A O-Ring continues to deliver fantastic performance when used in conditions that were just appointed for long periods where other elastomers fail.

What is an HNBR O-ring?

But what exactly is an HNBR O-Ring. Here I’ll explain everything. HNBR is a hydrogenated version of the standard NBR (nitrile rubber) which makes it more resistant to harsh substances/chemicals and very high & low temperatures. HNBR is classified as ‘heavily saturated nitrile’ (HSN) which means it is more robust than NBR. The O-Ring HNBR 70 Shore A is one of the best resistant to oils and hydraulic fluids (petroleum-based). As a result it retains its excellent quality and mechanical properties. Even under high pressure this O-Ring will deliver great performance because it is so flexible but also because of its hardness of 70 Shore A.

The HNBR O-Ring is highly resistant to oils, freon and other various solvents. This is due to the chemical composition that the hydrogenated nitrile O-Ring has, all in all it makes long-term durability a guarantee. The o-ring is resistant to ozone, ageing and weathering which significantly increases its lifespan even in harsh environments and this is because the hydrogenation process strengthens the polymer structure.

What’s the O-ring HNBR used for?

The O-Ring HNBR 70 Shore A has many improved properties and is used in various industries where they need to perform well in different types of conditions. These O-rings are used in the automotive industry and you will often see them in fuel injection systems, engine seals and power steering components Because they are so resistant to certain oils and temperatures. Due to their mechanical strength and resistance, they will not degrade in quality even when continuously exposed to certain fluids.

In the machinery industry, HNBR O-rings are most commonly used because they have great resistance to high pressure. This is crucial as they are placed in hydraulic systems, pumps and compressors. Also in the oil and gas industry, this O-ring plays a major role in pipelines, valves and drills where resistance to chemicals (such as natural gas, petroleum and synthetic lubricants) is necessary. This O-ring is the perfect choice when used when exposed to hydrocarbons. The HNBR O-Ring 70 Shore A is also widely used in aviation hydraulic systems and fuel controls. Because they operate in extreme environments involving high and low temperatures. This O-ring offers balance between flexibiltieti and durability which ensures great performance

Benefits of the hydrogenated nitrile O-ring

There are many advantages that the O-Ring HNBR 70 shore A offers. We have sorted them out for you.

  • Temperature resistance: The HNBR O-Ring - 70 Shore A withstands temperatures from -30 °C to +150 °C (-22 °F to 302 °F) and maintains his flexibility and sealing integrity.
  • Chemical resistance: It has a high tolerance to petroleum-based oils, hydraulic fluids and automotive coolants.
  • Mechanical Strength: With a hardness of 70 Shore A, HNBR offers high tensile strength and prevents extrusion under pressure (Extrusion: pressing of liquid mass through a moulding plate followed by cooling)
  • Durability: Resistant to ozone, weathering and oxidation for longer service life in harsh conditions.
  • Minimal swelling: Little volume change when exposed to fuels and lubricants, making the O-ring still reliable over time.

Disadvantages of the O-ring HNBR

Unfortunately there are also disadvantages that the O-ring HNBR 70 shore A has. We’ll explain these below.

  • Higher costs: Compared to standard elastomers such as NBR or EPDM the HNBR O-rings are more expensive because they are a lot more sophisticated.
  • Limited resistance to fluorine: despite being highly resistant to oils and chemicals the hydrogenated nitrile O-ring does not offer the same extreme resistance as FKM or FFKM materials.
  • Less flexibility in extreme cold: Despite the balance of hardness and flexibility offered by the 70 Shore A, performance may decrease at temperatures below -30°C.
  • Not ideal for dynamic sealing: For use with continuous movements or intense friction the HNBR O-ring is less suitable due to its limited tear and abrasion resistance.

Why choose O-ring Stocks?

At O-ring Stocks we offer high quality HNBR O-rings, designed to meet the most demanding requirements for optimal use in industry. Our selection of HNBR O-rings 70 shore A provides excellent chemical resistance and temperature resistance, ensuring long-term performance for heavy use or in high and low temperatures.  Whether you need a seal for the automotive industry or for use in oil and gas we offer reliability and quality with our hydrogenated nitrile O-rings. With a hardness of 70 Shore A the HNBR O-ring strikes a perfect balance between flexibility mechanical strength so that they are reliable even under high pressure.
